1-50ml Silin Bottle Linkage Line Product Brief Introduction:
This machine is composed of vertical ultrasonic bottle washer, hot air circulating oven and KFG series liquid filling and stopping machine for Xilin bottle. It can also be used alone. Suitable for the production of 1-50ml Silin bottle water needle. Can complete the ultrasonic cleaning, the last flushing water (fresh water for the second cycle) three times flushing, drying, sterilization, cooling, filling, aeration, plugging.
1-50ml Silin Bottle Linkage Line Product Description Features: 1-50ml Silin Bottle Linkage Line, 1-50ml Silin Bottle Linkage Line, 1-50ml Silin Bottle Linkage Line, 1-
1. The filling machine adopts the mode of transporting bottles with horizontal synchronous belt, which has high speed, accurate bottle division and convenient replacement of specifications.
2. There is a certain distance between the transport plane and the working table at the bottom of the bottle, which is conducive to the passage of 100-grade laminar air and prevents the contamination of liquid medicine by turbulent flow.
3. The filling part of filling machine adopts horizontal feeding plug and horizontal disc West plug, which has the characteristics of convenient observation, convenient feeding and high-speed feeding plug.
4. Filler can choose ceramic mercury, stainless steel mercury and creeping mercury.
5. Bottle-free and stoppage-free filling
6. Servo filling can be selected for filling machine (Delta, Mitsubishi, Rockwell)
7. Bottle washing machine uses manipulator to clamp bottles, which is suitable for bottles of various specifications.
8. Bottle washing with tracing insertion and air spraying has high quality and saves water.
9. Bottle wash water, clean water pipeline separated, no cross-contamination
10. Buffer block is added before the bottle screw of the bottle washer, which can protect the screw and reduce the broken bottle.
11. The whole imported synchronous belt is used for bottle washing and bottle discharging, and the bottle-pulling block is connected to deliver oral liquid. The operation is stable and reliable.
12. The oven is heated by hot air circulation, with uniform temperature and energy saving.
13. The oven can be equipped with circulating water-cooling device, which does not consume the room air volume, reduces the risk of extraordinary room pressure difference, and has good cooling effect.
14. Oven can be equipped with air pressure balancing device to reduce the high temperature deviation caused by the unbalanced pressure difference between room and oven, and a series of problems such as the temperature rise in the bathroom of filling room.
15. Touch screen can display the running dynamic of each single machine, the water pressure, air pressure, temperature of each control point, switch status and fault display, fault self-diagnosis and fault analysis and troubleshooting methods, so that the whole production process can be automated control, the line has three-machine automatic balancing device to ensure production balance and reliability.
parameter
Application for Specification
2-50ml national standard cillin bottle 2-50ml GB standard vials
Yield Capacity
200-400 bottles/min 200-400 vials/min
Vials breaking rate while washing
Less than 0.1%
Vials Qualified Washing Rate
More than 99%
Sterilization temperature
300-350 C
Filling Error of Loading Error
Less than < 2% (mechanical drive volume mercury, ceramics, stainless steel mercury)
< 2% (volume etric pump, ceranmics, stainless steel drived by mechanical system)
Filling Error of Loading Error
Servo Drive Volume Mercury (< 1%)
< 1% volumetric pump drived by servo system
Qualified Stoppering Rate
More than 99%
Air laminar flow cleanness
100 level 100C
Vacuum Ugly Fast Air Displacement
100 cubic meters/h (external) 100 cbm/H (optional)
Power supply
380V, 50HZ
Capacitance power
71KW
Gross weight
Approx 6500 KG
Exterior dimension
8357*2248*1900mm(L*W*H)
